4.7 CPU connection summary
4.7.1 CPU DB-9 Configuration port - P1
4.7.2 CPU digital I-O - J8
4.7.3 CPU frequency and analog I-O - J9
See programming manuals for configuration of I-O.
Terminal Function Notes
P1-2 Rx To PC, serial port, pin 3
P1-3 Tx To PC, serial port, pin 2
P1-5 Common To PC, serial port, pin 5
Terminal Function Notes
J8-1 Digital Input 1 Programmable via the user interface
J8-2 Digital Input 2 Programmable via the user interface
J8-3 Digital Input 3 Programmable via the user interface
J8-4 Digital Input 4 Programmable via the user interface
J8-5 Com Ground reference
J8-6 Digital Output 1 Programmable via the user interface
J8-7 Digital Output 2 Programmable via the user interface
J8-8 Digital Output 3 Programmable via the user interface
J8-9 Digital Output 4 Programmable via the user interface
J8-10 Com Ground reference
Terminal Function Notes
J9-1 Frequency Input (+)
Programmable via the user interface
J9-2 Frequency Input (-)
J9-3 Analog Output (+)
Programmable via the user interface
J9-4 Analog Output (-)
J9-5 Analog Input (+)
Programmable via the user interface
J9-6 Analog Input (-)
