K-TRON KCM - DC Drive Set-Up

5 KCM Set-Up
5.3 DC drive set-up
Page 60 Docu-No.: 1090020601-EN Rev. 1.2.1
5.3 DC drive set-up
5.3.1 DC drive selection notes:
• The 450 W dc drive provides a max at 2.50 Amps out. For 100 V
motors this corresponds to a max nameplate power of 240 W. For
200 V motors this corresponds to a max nameplate of 500 W.
• The 1600 W dc drive provides a maximum at 8.0 Amps out. For 100
V motors this corresponds to a max nameplate power of 800 W. For
200 V motors this corresponds to a max nameplate of 1600 W.
• The 450 W drive includes a voltage doubler that allows it to drive
180 V / 200 V motors from a 115 VAC input.
• The 1600 W drive does not have a voltage doubler, so to drive 180
V / 200 V motors it must have a 230 VAC input.
• DC drives auto-detect the input line voltage
5.3.2 DC motor selection table by drive type and line voltage
Drive Rating
Watts
Nominal AC
Input
VAC
Motor
Voltage
VDC
Nameplate
Motor Power
Watts (max)
450 115 / 230 90 225
450 115 / 230 100 250
450 115 / 230 180 450
450 115 / 230 200 500
1600 115 / 230 90 720
1600 115 / 230 100 800
1600 115 180 not allowed
1600 230 180 1140
1600 115 200 not allowed
1600 230 200 1600
