3 Technical Data
2.4 Safety devices and warnings
Page 24 Docu-No.: 1090020601-EN Rev. 1.2.1
Maximum output
power
DC motor-1600 watt drive:
800 W at 115 Vac nominal line
voltage
1600 W at 230 Vac nominal line
voltage
DC motor-450 watt drive:
225 W at 90 or 100 Volt motor
450 W at 180 or 200 Volt motor
Vibratory Drive:
Max. 60 W, 25-100 Hz
Stepper drive-0000005987:
1.4 or 2.46 A/coil peak per at
nominal line voltage (
194 watts)
Stepper drive-0000004568:
2.46 A/coil peak per at nominal line
voltage. (
194 watts)
Stepper drive-0000001430:
1.4 A/coil peak per at nominal line
voltage. (
49 watts)
Current range selected from motor
power settings.
DC motor output
voltage
With 115 Vac supply:
160 Vp, square-wave
PWM 0-99.6%
With 230 Vac supply:
322 Vp, square wave
PWM 0-99.6%
Stepper motor output
voltage
48 V maximum-(PWM)*
24 V maximum-(PWM)**
*For 0000005987 drive
**For 0000004568 and
0000001430 drives
Motor field output-dc Pulsing DC at 2A.
162 Vp DC at 115 Vac
325 Vp DC at 230 Vac
For dc motor drive. Special option
0000000639. Not for standard
KCM.
Maximum dc motor
speed
2500 rpm at 125% drive command Maximum input frequency from the
motor tachometer cannot exceed
10 kHz.
Speed accuracy
DC-motor
±1 rpm
Specification Limitations Notations
Table page 3 of 6
