KEB COMBIVERT F6

To Next Page

To Previous Page

Operating modes

167

co13 = 0

co13 active

1fghfh

Figure 52: Position precontrol

4.8.5.2 Status displays

In cyclic synchronous position mode, bit 11 and 12 are set op mode-dependent in

the statusword (0X2100 st00 / 0x6040).

st00

(CiA 0x6041) statusword

0x2100

Bit

Name

Note

internal

limit ac-

tive

This can be caused either by reaching of a torque or current limit (parameterized

or hardware-dependent).

drive fol-

lows com-

mand

value

Value 0: The drive does not follow the specification of target position.

Value 1: The drive follows the setpoint setting of target position.
