External error / warning triggering
Error reaction (=> see Chapter 4.3.1 Errors)
Selection of the inputs or events which trigger the error
Errors or warnings can also be triggered by external events. Different sources can
be selected via pn30.
The meaning of the single bits in pn30 prg. error source is defined as follows:
Input I1 triggers an error
Input I2 triggers an error
Input I3 triggers an error
Input I4 triggers an error
Input I5 triggers an error
Input I6 triggers an error
Input I7 triggers an error
Input I8 triggers an error
Input IA triggers an error
Input IB triggers an error
Input IC triggers an error
Input ID triggers an error
Safety Stop from safety module
safety stopping func-
tion
Error reaction (=> see Chapter 4.3.1 Errors)
On devices with safety module type 3 or higher, the SS1 or
SS2 function can directly execute the reaction set in pn80.
See also the instruction manual of the safety module.
