Number of passing timer units (max 2)
Setting the mode for the timer / counter block: Func-
tion is timer or counter
Definition of the reset behaviour
Definition of the counting behaviour
Selection if ru88, ru19, ru20 or ru18 is used as re-
lease for the counter
Selection which bit shall be used as release. De-
pending on the parameterization in do31 counter
unit mode, inverting of the bit can also be used as
reset or hold input
Selection if ru88, ru19, ru20 or ru18 is used as reset
input
Selection which bit is to be used as reset input
If no bit is selected here, the inverted release signal
must be programmed as reset source.
Selection if ru88, ru19, ru20 or ru18 is used as
counting input
Selection which bit is to be used as counting input
direction source parameter
Selection if ru88, ru19, ru20 or ru18 is used as
counting direction input
Selection which bit is used to specify the counting
direction
End value at which the counter is stopped
Display of the counter value
(identical parameter for the display in ms or events)
