KEB COMBIVERT F6 Programming Manual

DC link displays
196
© 2022 KEB Automation KG
5.4 DC link displays
Index
Id-Text
Name
Function
0x2C04
ru04
supply unit state
Charging status of the DC link:
- 5: phase failure => DC voltage lower than required for oper-
ation
- 2: charging => Load-shunt-delay time is running
- 4: run => Operation (modulation release) possi-
ble
0x2C0E
ru14
act. Uic voltage
Voltage in DC link [0.1V]
0x2C0F
ru15
peak Uic voltage
Peak value of the DC voltage
is deleted by Power-On or overwritten with the value 0
5.5 Current displays
Index
Id-Text
Name
Function
0x2C0A
ru10
act apparent current
Motor apparent current [0.01A]
0x350C
is12
display apparent
current PT1
Smoothing time for the motor current display in ru10
0x2C0D
ru13
peak apparent current
Peak value of unsmoothed motor apparent current
Deletion by Power-On or overwriting with 0
0x2C0B
ru11
act active current
Active current [0.01A]
0x2C0C
ru12
act reactive current
Reactive current [0.01A]
0x2C49
ru73
Imot/Imax OL2
Ratio of the actual motor current to short time current limit
[0.1%]
0x2C39
ru57
eff. motor load
Mean effective motor load [0.1%]
5.6 Torque displays
Index
Id-
Text
Name
Function
Resolution
0x2C17
ru23
reference torque
Reference torque (output of the speed controller)
1000 =
100%
dr09 rated
torque
0x2C18
ru24
actual torque
Actual torque (COMBIVIS display in %)
0x2122
st34
torque actual value
Actual torque (COMBIVIS display unnormalized)
0x350D
is13
display torque PT1
Smoothing time for the torque display in ru23 / ru24 /
ru81
1000 = 1ms
0x2C19
ru34
act torque lim mot for
Torque limits, which result from the settings in cs12 …
cs16 or in the profile parameters 0x60E0 / 0x60E1.
The final limits can be different due to the influence of
the limiting characteristic or the operation mode (e.g.
fault reaction ramp).
1000 =
100%
dr09 rated
torque
0x2C1A
ru35
act torque lim mot
rev
0x2C24
ru36
act torque lim gen for
0x2C25
ru37
act torque lim gen
rev
