Digital outputs
460
©
2022
KEB Automa
tion KG
7.2.9.7
Filter
A filter can be series
-connec
ted for each comparison o
peration.
Index
Subidx
Id
-Text
Name
Function
0x2608
1…8
do08
filter time flags
Filter for the compariso
n operation
The filter is incremented
if the output of the co
mparator level is = TRUE
, at False it is dec-
remented.
Switching the filter out
put o
ccurs only at counter re
ading = 0 (clearing the f
ilter output) or
at counter reading = adjus
ted filter time (sett
ing the filter outp
ut).
Times are rounded to
ms.
2
1
1
f
g
h
f
h
1
Figure 126: Filter for the comparison operation
0
1
Signal
von Komperatorstufe
0
1
Ausg
ang
0
2
4
6
Zähler
459
461
