Brake control

4.2 Brake control

WARNING

Customer evaluation of the brake control!

The brake control is influenced by other functions (e.g. position con-

trol) depending on the process.

➢ Always evaluate brake control in the customer application.

➢ List and test possible braking scenarios.

➢ Check scenarios again if changes are made in the application.

Specification brake control F6-A / S6-A or F6-P S6-P

For more information, please refer to the instruction manual of the safety module

and the installation instructions of the control board.

Specification brake control F6-K / S6-K

The max. permissible current for the brake is 2A.

If a fault current is exceeded, error 68 "ERROR" overcurrent brake is triggered. The

response threshold of the error is between 2.5A and 4A.

Thus the brake control is short-circuit protected.
