KEB COMBIVERT F6 Programming Manual

Protection functions
64
© 2022 KEB Automation KG
Overtemperature unit (OHI)
NOTICE
The inverter is not a temperature measuring device!
➢ The detection of the temperature only serves to protect the inverter
and is, depending on the device type and the current measuring
point, subject to varying degrees of tolerance and error.
Index
Subidx
Id-Text
Name
Function
0x2C1A
0
ru26
internal temperature PU
values
Internal temperature in the power unit (PowerUnit)
at different points (depending on the inverter size)
1
internal temperature PU 1
Internal temperature in the power unit measuring
point 1
2
internal temperature PU 2
Internal temperature in the power unit measuring
point 2
3
internal temperature PU 3
Internal temperature in the power unit measuring
point 3
4
minimal distance to OHI
Display of the smallest difference between an inter-
nal temperature and the associated error trigger
value
0x2C4D
0
ru77
internal temperature CB
Internal temperature on the control board (Con-
trolBoard)
0x2A06
0
pn06
temperature warning set-
ting mode
Selection of the reference level for generating the
overtemperature warning
0x2A09
0
pn09
OHI warning level
Internal temperature (of the power unit or control
board) when OHI warning is triggered
0x2A0A
0
pn10
E.OHI stop mode
Error reaction (=> see Chapter 4.3.1 Errors)
0x2A52
0
pn82
warning OHI stop mode
Error reaction to pre-warning (=> also chapter 4.3.1
Errors)
0x2C02
0
ru02
warning bits
Display of the warnings bit-coded (=> 4.3.3 Warn-
ings)
0x2A1C
0
pn28
warning mask
Mask for warning bit in the status word (=> 4.3.3
Warnings)
The internal temperature is measured at several points, with one sensor on the
control board and one or more sensors in the power unit.
On reaching an unit-dependent maximum internal temperature, the drive behaves
according to the setting of pn10 E.OHI stop mode.
The length of time required to shutdown the drive depends on many factors. The
maximum time between occurence overtemperature and switch-off modulation is 2
seconds.
If the time exceeds 2 seconds and the overtemperature error is still present, it will
be switched off with error message 111: ERROR time OHI.
If these 2 seconds are too small to ensure a meaningful completion of the machine
cycle, a warning level pn09 OHI warning level can be programmed. Upon reaching
this temperature, bit 3 is set in ru02 warning bits and with respective setting of the
warning mask also bit 7 in the status word.
