Status LED

480

Fieldbus state (NET ST)

A detailed description of the different light pattern for the different fieldbus types can be

found in the installation manual of the control board.

Drive controller state (DEV ST)

red: There is an exception. ru01 != 0

yellow: no error, DC link not loaded

green: no error, ready for operation

Identification of the unit can additionally occur via the DEV ST LED. The DEV ST LED

flashes permanently by activating with fb32.

Index

Id-Text

Name

Function

0x2B20

fb32

LED 'DEV ST' blink status

Visual identification of the unit

fb32

unit identification

0x2B20

Value

Name

Note

off

DEV ST LED with continuous light

DEV ST LED flashes

FS Status (control type A and P)

The description of the function of the FS ST LED (status LED safety module) occurs in

the safety manual for the corresponding module.
