KEB COMBIVERT F6

Inverter data
© 2022 KEB Automation KG
213
Device type, software version and date
The hardware version of the control board can be differentiated with de13.
de13
ctrl type
0x200D
Bit
Function
Value
Plaintext
Notes
for control type F6-K
0…1
bus-type
0
EtherCAT/Can
Fieldbus type supported by the hardware
1
VARAN/Can
2…5
Hw-version
4
3
only external 24V supply
for control type S6-K
0…1
bus-type
0
EtherCAT/Can
Fieldbus type supported by the hardware
1
VARAN/Can
for control type F6-A
0
Hw-version
1
1
not PCB version 1A
for control type x6-P
0..7
Hw-version
4
enc. intf. + relay + 485
5
no enc. intf. + safety relay
6
enc. intf. + safety relay
15..8
hardware
type
256
F6
512
S6
23..16
safety type
327680
sm type 5
The device type can be differentiated within a device series (F6/S6) with de15.
de15
ctrl type
0x200F
Bit
Function
Value
Plaintext
Notes
0…7
modul
type
32
module: SAM
Definition of the software type (single axis module)
8…15
hardware
type
8192
Control K /
EtherCAT
Determination of the control and/or fieldbus type CAN is addi-
tionally included with all types.
(Exception: a hardware revision for control type P)
With control type A or P the fieldbus type is independent of the
hardware
8448
Control K /
VARAN
12288
Control A
16384
Control P
