KEB COMBIVERT F6 Programming Manual

Speed displays
© 2022 KEB Automation KG
193
5.2 Speed displays
Set value displays:
Index
Id-Text
Name
Function
Resolution
0x2C05
ru05
set value display
Setpoint speed display before ramp generator in
state OPERATION ENABLED at mode of oper-
ation = 2 „velocity mode“
1/8192 rpm
0x2C06
ru06
ramp out display
Set speed for speed controller after ramp gener-
ator and the PT1 filter of the set speed (cs19 ref
speed PT1-time)
1/8192 rpm
0x2103
st03
vl velocity demand
Set speed at the ramp generator output
1 rpm
0x2C54
ru84
ref. value display
Setpoint speed display before ramp generator
(operating mode independent)
1/8192 rpm
0x2C55
ru85
actual speed PT1
filtered actual speed
(ru08 to PT1 filter / filter time constant = is39)
1/8192 rpm
0x2C56
ru86
standard set speed
ru86 displays the setpoint that would be active if
the blockade function did not determine the set-
point speed
1/8192 rpm
0x2C57
ru87
ramp out value
smoothed ramp output value (smoothing ac-
cording to cs19; see point B in Figure 60)
1/8192 rpm
Actual speed / frequency displays:
Index
Id-Text
Name
Function
Resolution
0x2C07
ru07
act. frequency
Actual output frequency
1/8192 Hz
0x2C08
ru08
act. value
Actual speed:
- measured speed at control mode
with encoder
- estimated speed at ASCL / SCL
- ramp output speed at v/f control
1/8192 rpm
0x2C09
ru09
act. encoder speed
Actual speed measured with encoder
1/8192 rpm
0x2120
st32
velocity actual value
Current actual speed as ru08 normalized by the
velocity shift factor co02
defined by
co02
0x2C55
ru85
actual speed PT1
filtered actual speed (ru08 after PT1 filter with
the time constant is39 / 0 = filter switched off)
1/8192 rpm
Difference speed displays:
Index
Id-Text
Name
Function
0x2C53
ru83
diff. speed [1]..[4]
Difference between setpoint speed and actual speed
Description see previous chapter:
5.1 Overview of the ru parameters and Figure 60
