KEB COMBIVERT F6 Programming Manual

Overview of the ru parameters
192
© 2022 KEB Automation KG
Index
Id-Text
Name
Function
0x2C52
ru82
actual power
Structure of power displays
mechanical power [1]
Mechanical shaft power
electrical output power [2]
Electrical output power of the converter
electrical power loss [3]
Power loss
(= emitted active power by the inverter - emitted shaft
power)
out. energy mot.[4]
Motor energy
(integrated value of the positive (motor) electrical output
power[2])
out. energy mot. volatile[5]
Motor energy during a power-on cycle
(Value is deleted when the 24V supply is switched off)
out. energy gen.[6]
regenerative energy
(integrated value of the negative (regenerative) electrical
output power[2])
out. energy gen. volatile[7]
regenerative energy during a power-on cycle
(Value is deleted when the 24V supply is switched off)
0x2C53
ru83
diff. speed
Structure of differential speed displays (is also calculated
when the modulation is switched off)
diff. speed [1]
Difference between speed setpoint (ru84) and actual
speed value (ru08)
diff. speed [2]
Difference of not smoothed ramp output value (see A in
Figure 60) and actual speed value (ru08)
diff. speed [3]
Difference of smoothed ramp output value (smoothing af-
ter cs19; see B in Figure 60) and actual speed value
(ru08)
diff. speed [4]
Difference (see C in Figure 60) of smoothed ramp output
value with position controller influence (ru06) and actual
speed value (ru08)
0x2C54
ru84
ref. value display
preset setpoint speed (in each operating mode)
0x2C55
ru85
actual speed PT1
filtered actual speed
(ru08 to PT1 filter / filter time constant = is39)
0x2C56
ru86
standard set speed
actual setpoint speed, but this can be overwritten by the
blockade function.
ru86 displays the setpoint that would be active if the
blockade function did not determine the setpoint speed
0x2C57
ru87
ramp out value
smoothed ramp output value (smoothing according to
cs19; see point B in Figure 60)
