KEB COMBIVERT F6 Programming Manual

Overview of the ru parameters
© 2022 KEB Automation KG
191
Index
Id-Text
Name
Function
0x2C2A
ru42
AN1 value display
Analog input value of AnalogIn 1
0x2C2B
ru43
AN1 after gain display
Analog input value of AnalogIn 1
0x2C2A
ru44
AN2 value display
Analog input value of AnalogIn 2
0x2C2B
ru45
AN2 after gain display
Analog input value of AnalogIn 2
0x2C30
ru48
analog REF display
=> Chapter 7.3.4 Calculation of REF and AUX
0x2C31
ru49
analog AUX display
=> Chapter 7.3.4 Calculation of REF and AUX
0x2C32
ru50
act. torque lim. pos.
Actual torque limit (after consideration of limiting character-
istic, current limits, etc.)
0x2C33
ru51
act. torque lim. neg.
0x2C34
ru52
system date
Date: 32 bit counter with 1s resolution from
1th January 1970 00:00.
(=> 5.9.1
Real time
clock)
0x2C35
ru53
system time
Time: 32 bit counter with 1ms resolution from
00:00.
0x2C39
ru57
eff. motor load
mean effective motor utilization
0x2C3A
ru58
actual index
Actual index. Results from the state of the inputs, which are
selected with di21 index input for the index setting.
0x2C63
ru63
Uic voltage at Power On
Measured DC link voltage at the end of the precharging
0x2C48
ru72
act. switch. freq
Actual switching frequency
0x2C49
ru73
Imot/ImaxOL2
Ratio of the actual motor current to short time current limit
0x2C4A
ru74
unfiltered flags state
State of the unfiltered flags
(=> Chapter 7.2 Digital outputs)
0x2C4B
ru75
global drive state
Global status display
0x2C4C
ru76
drive state
Global overview over the drive state
0x2C4D
ru77
internal temperature CB
Internal temperature control board
0x2C4E
ru78
analog out display
Value of the analog output in % (100% = 10V)
0x2C50
ru80
relative torque
Current torque referred to a limit value
(Description => Chapter 5.6 Torque displays)
0x2C51
ru81
act torque
Actual torque (identical ru24) in Nm
