KEB COMBIVERT F6 Programming Manual

Interface to the encoder
© 2022 KEB Automation KG
247
SSI data format ec42 SSI data format
Index
Id-Text
Name
Function
0x282A
0x482A
ec42
SSI data format
Selection of the SSI data format
These are the setting possibilities according to the SSI specification:
ec42
SSI data format / SSI data format B
0x282A / 0x482A
Bit
Function
Value
Plaintext
Function
0…1
SSI PFB mode
0
PFB off
no Power Fail Bit
1
PFB at start of da-
taword
Power Fail Bit at the beginning of the posi-
tion value (before MSB)
2
PFB at end of da-
taword
Power Fail Bit at the end of the position
value (after LSB)
3
reserved
Reserved
2
even parity
check
0
no parity check
No parity check
4
even parity check
Even parity check
3
Data format
0
fir tree
Fir tree
8
serial right aligned
Serial right-justified
4
SSI data code
0
binary
Binary code
16
gray
Gray code
Some encoders send in addition to the position values ec40 and ec41 an error bit
(often called Power Fail Bit PFB) which is 0 in normal operation and becomes 1
when the encoder detects an error status, e.g. operating voltage too low.
When a PFB is set, an additional clock is automatically output to read this bit. I.e.
ec40 and ec41 remain unaffected.
If the encoder has a PFB and the data word is gray coded, the PFB must also be
gray coded. In contrast, this variant is not supported: Only the position value is
gray coded and then the PFB is attached.
The fir tree data format is rarely found today. Most encoders have the serial-right
data format, so this should be set first.
SSI clock frequency ec43 SSI clock freq.
Index
Id-Text
Name
Function
0x282B
0x482B
ec43
SSI clock freq.
Selection of the SSI transmission clock frequency
The following frequencies can be selected:
ec43
SSI clock freq.
0x282B / 0x482B
Value
Clock frequency
0
100 kHz (156 kHz)
1
500 kHz
2
1 MHz (833 kHz)
The values in brackets apply if Endat is adjusted on the other encoder channel.
