KEB COMBIVERT F6 Programming Manual

Motor parameterization
© 2022 KEB Automation KG
293
Application-specific data
The following items are not complete, but these values must be checked at least.
base is operating mode velocity mode.
Speed limits
Speed limits can be parameterized in the vl parameters for the velocity mode
Torque limits
dr11 max torque
Torque limit of the motor
cs12 absolute torque
Torque limit of the application (is valid in all quad-
rants)
cs13…cs16
Torque limits for the single quadrants
dr13 breakdown torque
Torque for the definition of the speed-dependent
limiting characteristic. This value must be in-
creased, if the torque reduction according to a
1/x^2 characteristic starts to early.
Current limits
de29 inverter maximum
current
only display / maximum current for control
dr12 max current
Maximum current of the motor
is11 max current
The maximum current of the inverter can be de-
creased here (e.g., if the limit for the control should
be lowered at motors with high current ripple in or-
der to avoid overcurrent errors)
is35 set current limit
Setting of the maximum current for control (defines
the safety distance to the overcurrent switch-off
threshold)
Ramps
co48…co51
Values for acceleration / deceleration
co52…co59
Values for the jerk in different ramp phases
co60
General parameterization of the ramp generator
