Calculation of the reference idle current
4.1
• Magnetizing current (Chapter 6.2.5 )
• Maximum voltage (Chapter 6.2.10.3 )
• Synchronous motor with reluctance torque (Chapter 6.2.5.2.3 )
• Model stabilization
• Stabilisation current / standstill current (only SCL) (Chapter 6.2.16.3 )
• Sine-wave filter and capacitor current compensation (Chapter 6.2.23 Sinus filter)
4.2
Limitation to the max. reactive current
• Current (Chapter 6.2.8 )
5
Adaptation and saturation characteristic of the motor equivalent circuit diagram data
5.1
Motor model
• Rotor position detection in operation at SCL (hf injection) (Chapter 6.2.3.6 )
• Model control (ASM and SM) (Chapter 6.2.16 )
• Model stabilization
• Stabilisation current / standstill current (only SCL) (Chapter 6.2.16.3 )
• Adaption (Chapter 6.2.12 )
5.2
Saturation characteristic
• Saturation characteristic (SM) (Chapter 6.2.13 )
5.3
Adaption (only with motor model)
• Adaption (Chapter 6.2.12 )
• Control mode (with encoder / encoderless) (Chapter 6.2.15 )
6
Motor model with estimated rotor position (only for SM)
6.1
Speed estimation
• Model control (ASM and SM) (Chapter 6.2.16 )
• Model stabilization
• Stabilisation current / standstill current (only SCL) (Chapter 6.2.16.3 )
6.2
Rotor position detection (SM)
• Rotor position detection in operation at SCL (hf injection) (Chapter 6.2.3.6 )
• System offset (Chapter 6.2.3.5 )
7
Encoder evaluation
• Parameterization of the encoder system (Chapter Interface to the encoder 6.1)
• System offset (Chapter 6.2.3.5 )
8
Control mode
• Control mode (with encoder / encoderless) (Chapter 6.2.15 )
