KEB COMBIVERT F6 Programming Manual

Motor parameterization
© 2022 KEB Automation KG
303
6.2.5.2.3 Synchronous motor with reluctance torque
If the inductances Ld and Lq are different, a reluctance torque can be generated by
setting a d-current component (magnetizing current) which amplifies the torque
generated by the magnets.
This effect is particularly pronounced at IPM motors.
Operation with encoder feedback:
The Id-current must be preset depending on the actual set torque of the speed
controller for optimal operation (preferably low motor current).
In this way losses and possible inverter size can be reduced.
mo03
Fill table sel. (mo04…mo10)
0x3803
Bit
Func-
tion
Value
Plaintext
Notes
0
sel.
0
ctrl card
The tables are filled by writing on mo00, mo03 and dr99,
ds04. Here, Id is set to 0A and depending on the saturation
coefficients, the current for Iq = f(M) is calculated.
mo09 from dr12
mo10 from dr11
1
external
The tables must be filled externally.
Index
Id-Text
Name
Function
0x3804
mo04
Isq opt. Array(Iq=f(M))
ARRAY (16, float32, [A])
0x3805
mo05
Isd opt. Array(Id=f(M)
ARRAY (16 ,float32, [A])
0x3806
mo06
MLim array (M=f(Imax))
ARRAY (16 ,float32, [Nm]), this table is the result of
mo04, mo05, if mo03 selection = 0 "ctrl card“ is selected
0x3809
mo09
Current Tab. x-axis
Reference value for the x-axis (float32 [A]]
0x380A
mo10
Torque Tab. x-axis
Reference value for the x-axis (float32 [Nm]]
Operation without encoder feedback:
At operation without encoder feedback (SCL), the table mo05 must be filled with
zeros when the high-speed model (ds30) is selected. The optimum apparent cur-
rent is given automatically.
