The function is defined by parameters dr13 and dr25.
Index
Id-Text
Name
Function
0x220D
dr13
breakdown torque %
Breakdown torque at start of field weakening
0x2219
dr25
breakdown speed %
Field weakening point
The breakdown torque in % of the rated torque is entered in dr13 breakdown
torque %. 100% can always be entered in dr25 for an asynchronous motor.
Example: Parameterization of dr13 and dr25 for an asynchronous motor
Rated values
Limiting characteristic
Rated voltage
330 V
Reference-DC link voltage
565 V
Rated fre-
quency
50 Hz
M
breakdown
/ M
rated
2
Pole-pair num-
ber
2
Rated speed
1460 rpm
   

 


 
The field weakening shall start at this frequency => dr25 = 100%
 


  


   
6.2.10.5.2 Synchronous motor
Theoretically, the maximum torque must decrease at sufficient high current in the
d-axis according 1/x characteristic.
ds11
torque mode
0x240B
Bit
Function
Value
Plaintext
Notes
0…1
field weak curve
limit
0
1/x
for SM
Adjusts itself automatically depending on the
selected motor type
1
1/x²
for ASM
This means: ds11 torque mode Bit 0/1 field weak curve limit must be set to 0: 1/x.
A 1/x function is defined by specifying a single point which is passed through. This
point is determined by parameters dr13 and dr25.
Index
Id-Text
Name
Function
0x220D
dr13
breakdown torque %
Torque and speed for the definition of the limiting
characteristic
0x2219
dr25
breakdown speed %
dr25 defines the speed and dr13 defines the limit characteristic (max.) torque
which is appropriate to this speed.)
The torque value is entered in dr13 breakdown torque % in % of the motor rated
torque.
The speed value is entered in dr25 breakdown speed % in % of the rated field
weakening speed . This is calculated as follows:
