Motor parameterization

336

cs00

control mode

0x2700

Bit

Func

tion

Value

Plaintext

Notes

spee

d ctrl

mod

Kp/Tn, no adapt

The calculation of KP/Tn is done with the actual ad-

justed mode (with encoder or encoderless).

The controller gain remains unchanged at mode

change

kp/Tn, adapt in-

ternal

The calculation of KP/Tn always occurs for the mode

with encoder. At mode change the controller gain is in-

ternal adjusted depending on the smoothing times.

The ratio of the smoothing times for encoderless oper-

ation (ds28) and operation with encoder (ec26/2 +

ec27) should be in the range of 1/16….16.
