KEB COMBIVERT F6 Programming Manual

Errors and warnings
© 2022 KEB Automation KG
41
ru01
Error text (continuation)
Description
st01
145
ERROR invalid resistor data
invalid data for the sub-mounted braking resistor
0x1000
146
ERROR analog input 4..20mA
Monitoring of the 4..20mA interface has triggered
an error (with appropriate programming)
0x1000
4.3.1.2 Programmable error response
Many errors require an immediate shutdown of the modulation. Thus the motor
coasts down.
The response to errors / malfunctions which do not require immediate modulation
shutdown can be set in the pn parameters.
4.3.1.2.1 Configurable errors
The behaviour can be programmed for the following errors:
Index
Id-Text
Name
Possible error response
Fault
Fault
ramp
Stop
ramp
Warning /
Ignore
0x2A04
pn04
ERROR OL stop mode
x*
x
0x2A08
pn08
ERROR OH stop mode
x*
x
0x2A0A
pn10
ERROR OHI stop mode
x*
x
0x2A0C
pn12
ERROR dOH stop mode
x*
x
x
x
0x2A10
pn16
ERROR OH2 stop mode
x*
x
x
x
0x2A14
pn20
ERROR SW-switch stop mode
x
x
x
x*
0x2A16
pn22
ERROR fb watchdog stop mode
x
x
x
x*
0x2A1B
pn27
ERROR overspeed stop mode
x*
x
x
x
0x2A1D
pn29
prg. error stop. mode
x
x
x
x*
0x2A22
pn34
ERROR encoder A stop mode
x*
x
0x2A23
pn35
ERROR encoder B stop mode
x
x*
0x2A25
pn37
ERROR max acc/dec stop mode
x
x
x
x*
0x2A28
pn40
ERROR speed diff stop mode
x
x
x
x*
0x2A47
pn71
E. overspeed (EMF) st. mode
x*
x
x
x
0x2A49
pn73
E.enc A changed stop mode
x
x
x*
0x2A4A
pn74
E.enc B changed stop mode
x
x
x*
0x2A4D
pn77
E.UP2 stopping mode
x
x*
0x2A4E
pn78
ERROR limit switch forward reaction
x
x
x
x*
0x2A4F
pn79
ERROR limit switch reverse reaction
x
x
x
x*
0x2A50
pn80
safety stop mode
x
x
x
x*
0x2A51
pn81
warning OH stop mode
x
x
x
x*
0x2A52
pn82
warning OHI stop mode
x
x
x
x*
0x2A56
pn86
E.AnIn stop mode
x
x
x
x*
0x2A59
pn89
warning brOH stop mode
x
x
x
x*
* = Default value
