KEB COMBIVERT F6 Programming Manual

Digital Inputs
428
© 2022 KEB Automation KG
7.1.7.1 Configuration of the inputs
di28 defines the controlword bits on which the status of the controlword inputs de-
pends on.
di28[1]
di28[2]
cw input 1
cw input 2
0x321C
Bit
Value
Plaintext
Note
0
1
copy bit 11 to cw input x
If one of the selected controlword bits is set, the
corresponding controlword input (cw 1 or 2) is
set
1
2
copy bit 12 to cw input x
2
4
copy bit 13 to cw input x
3
8
copy bit 14 to cw input x
4..15
reserved
without function
7.1.7.2 Display of the inputs
there are 2 new bits in the display of ru18 and in the selection tables of the digital
input functions for which the use of the controlword inputs seems reasonable: 12 /
13 controlword input x => CW x.
For functions for which the use of the controlword inputs is not recommended, "re-
served" is displayed instead of CW 1 / CW 2. If this bit is used, the corresponding
function is also executed.
ru18
dig. input state
0x2C12
Value
Bit
Name
Function
1
0
I1
Input state I1
2
1
I2
Input state I2
4
2
I3
Input state I3
8
3
I4
Input state I4
16
4
I5
Input state I5
32
5
I6
Input state I6
64
6
I7
Input state I7
128
7
I8
Input state I8
256
8
IA
Input state IA
512
9
IB
Input state IB
1024
10
IC
Input state IC
2048
11
ID
Input state ID
4096
12
CW 1
Input state controlword input 1
controlword inputs
8192
13
CW 2
Input state controlword input 2
16384
14
STO-1
Channel 1 from the safety
module
Can not be changed by the input
block
32768
15
STO-2
Channel 2 from the safety
module
