Digital Inputs

433

7.1.9.1 Controlword functions via the digital inputs

All controlword functions can also be activated with digital inputs by di10… di15

and di18, di19:

• specific bits (di10 RUN input , di11 RST input, di19 start posi/homing input,

di23 halt input)

• any bits of the controlword via di12..di15. (The mask objects di13 CA mask

and di15 CB mask are used to select which bits are preset via the digital

inputs.

The inputs, which determine the state for the selected bits are selected

with di12 CA input and di14 CB input).

The status of the digital inputs is taken from parameter ru18 digital input state.

The status of the controlword bits influenced via digital inputs is visible in in di29

digital input controlword.
