KEB COMBIVERT F6 Programming Manual

Digital Inputs
© 2022 KEB Automation KG
447
The values in the input function parameters have the following meaning:
di30…di45
Ix / STOx / CW x input function Subindex 1
0x321E…322B
Bit
Value
Plaintext
Function
0…31
0
not defined
No function is assigned to the input
0
1
Run
di10: Run
For a description of the
input function refer to
the respective parame-
ter which they are as-
signed to.
1
2
RST
di11: RST
2
4
CA
di12: CA mask
3
8
CB
di14: CB mask
4
16
FOR
di16: FOR
5
32
REV
di17: REV
6
64
Stop
di18: Stop
7
128
OS4
di19: Start Posi, Start Homing
8
256
inv
di20: invert
9
512
index
di21: index
10
1024
neg. lim
hm06: negative limit switch
11
2048
pos. lim
hm07: positive limit switch
12
4096
home
hm08: home switch
13
8192
home src
hm14: home mode source
14
16384
imm
ps44: immediately input
15
32768
error
pn30: prg error source
16
65536
brk. res.
pn31: enable braking trans. source
17
131072
end src.
pn46: fault reaction end src
18
262144
trigger
of05: trigger source
19
524288
HALT
di23: HALT
20
1048576
start recipe
ud03: start recipe
21
2097152
start dc-braking
ds61: start dc-braking
22
4194304
activate jog mode
cm34: activate jog mode
23
8388608
jog positive
cm35: jog positive
24
16777216
jog negative
cm36: jog negative
25
33554432
act. jog speed 2
cm37: activate jog speed 2
26
67108864
jog step mode
cm38: jog step mode
27
134217728
jog inc MOP
cm31: jog inc MOP
28
268435456
jog dec MOP
cm32: jog dec MOP
29
536870912
jog reset MOP
cm33: jog reset MOP
di30…di45
Ix / STOx / CW x input function Subindex 2
0x321E…322B
Bit
Value
Plaintext
Function
0…31
0
not defined
No function is assigned to the input
0
1
PID reset I term
an70: PID reset integral term input
For a description of the
input function refer to
the respective parame-
ter which they are as-
signed to.
1
2
deactivate PID
an71: PID deactivation input
2
4
fade out input
an73: PID fade out input
3
8
USV enable input
pn43[2]: USV enable input
4
16
strobe input
di24: strobe input
