KEB COMBIVERT F6 Programming Manual

Digital outputs
464
© 2022 KEB Automation KG
The meaning of the values is identical for do20…do27.
do20…do27
select flag O1…OC, Relais
0x2614…0x261B
Bit
Valu
e
Name
Function
0
1
F1
Result function block 1
If several function blocks are selected
for one output, the selected flags are
OR-connected (output is set if at least
one flag is set) or AND-connected
(output is set if all assigned flags are
set).
The type of connection is defined in
do19.
1
2
F2
Result function block 2
..
..
..
...
7
128
F8
Result function block 8
8
256
CF1
Result linked function blocks 1
..
..
..
11
2048
CF4
Result linked function blocks 4
do19
AND operation for output
0x2613
Bit
Value
Name
Function
0
0
O1
Selected flags for O1 are AND linked
1
Selected flags for O1 are AND linked
1
0
O2
Selected flags for O2 are OR linked
2
Selected flags for O2 are AND linked
2
0
O3
Selected flags for O3 are OR linked
4
Selected flags for O3 are AND linked
3
0
O4
Selected flags for O4 are OR linked
8
Selected flags for O4 are AND linked
4
0
OA
Selected flags for OA are OR linked
16
Selected flags for OA are AND linked
5
0
OB
Selected flags for OB are OR linked
32
Selected flags for OB are AND linked
6
0
OC
Selected flags for OC are OR linked
64
Selected flags for OC are AND linked
7
0
Relay
Selected flags for the relay are OR linked
128
Selected flags for the relay are AND linked
7.2.12.2 Example
Example: Output O1 shall be set if the 3 inputs I1 and I2 and I3 are set:
Definition Flag 1 (I1 set => Bit 0 ru18 set):
do01 flag operand A [1] = 18 “dig. input state (ru18)”
do02 flag operand B [1] = 28 “level 2 (do06)”
do06 flag level 2 [1] = 1
do03 flag operator mode [1] = 3 “AND”
Definition flag 2 (I2 set => Bit 1 ru18 set):
do01 flag operand A [2] = 18 “dig. input state (ru18)”
do02 flag operand B [2] = 28 “level 2 (do06)”
do06 flag level 2 [2] = 2
