Protection functions

When the setpoint is reached, the standard ramp becomes active again.

If the setpoint speed at the start of the alternative ramp is zero, the standard ramp

is also reactivated

pn84[3]

auto retry UP acceleration for [s-2]

0x2A54 SubIdx 3

Value

Plaintext

Function

0: off

no alternative ramp

0 .. 1747626666

0,00 .. 17476266,66

Definition of the alternative ramp
