Protection functions
© 2022 KEB Automation KG
99
Index
Subidx
IdTxt
Name
3920h
7
cu32
power-off . state
Bit
Func-
tion
Valu
e
Plaintext
Note
0
mains
ok
0
OK
Assumed mains status OK
1
phase failure
Assumed mains status FALSE
1…3
power
off
state
0
off
not active
2
active (DC-ctrl)
Active
4
active (DC-
ctrl), no auto
restart
Active, no auto restart possible
6
stopping
Drive decelerates to ZERO
8
stopping, no
auto restart
Drive decelerates to ZERO, no auto restart possi-
ble
10
end, ERROR
reset
Power Off expired, error message
4…8
re-
served
4.4.22.6 Figure in the drive state machine
Since the power-off function is active while the CDM is decoupled from the setpoint
setting, the power-off function is displayed as a separate state in the drive state
machine.
A change into the state power-off-active (st00 bit 14 and st12 value 13) can be
done from the following states:
• Operation enabled
• Shutdown active
• Disable operation active
• Quickstop active
It is not possible to change from "fault reaction active" state to power-off.
When a system recovery is detected, the following state transitions are possible:
• Operation enabled (if the restart speed limit has not fallen below yet)
• Power – off active (drive continues deceleration and completes power-off
function)
The following state transitions are possible when the power-off function has been
terminated:
• Fault (after expiry of the deactivation time)
A change to the state "Switch on disabled" can be made at any time using the com-
mand "Disable Voltage".
