The Modulation Line configuration of the External PTT (Voice) of KPG-D1/ D1N and the Mic Lines enabled when each
External PTT (Voice) port (AUX Input) is operated are as follows:
Table 16-3 Mic Line (External PTT (Voice)) (Without Bluetooth)
Modulation Line Setting
Operation Mic Input
Mic Line MI2 Line
Disconnect Disconnect
Control Head 1 -
The External PTT (Voice) port goes low
level.
None
Control Head 2 -
The External PTT (Voice) port goes low
level.
None
Selected RF Deck -
The External PTT (Voice) port goes low
level.
None
Unselected RF Deck -
The External PTT (Voice) port goes low
level.
None
Connect Disconnect
Control Head 1 -
The External PTT (Voice) port goes low
level.
Control Head 1 - Mic Line
Control Head 2 -
The External PTT (Voice) port goes low
level.
Control Head 2 - Mic Line
Selected RF Deck -
The External PTT (Voice) port goes low
level.
Control Head 1 - Mic Line
Unselected RF Deck -
The External PTT (Voice) port goes low
level.
None
Disconnect Connect
Control Head 1 -
The External PTT (Voice) port goes low
level.
Selected RF Deck - MI2 Line
Control Head 2 -
The External PTT (Voice) port goes low
level.
Selected RF Deck - MI2 Line
Selected RF Deck -
The External PTT (Voice) port goes low
level.
Selected RF Deck - MI2 Line
Unselected RF Deck -
The External PTT (Voice) port goes low
level.
Unselected RF Deck - MI2 Line
Connect Connect
Control Head 1 -
The External PTT (Voice) port goes low
level.
Control Head 1 - Mic Line
Selected RF Deck - MI2 Line
Control Head 2 -
The External PTT (Voice) port goes low
level.
Control Head 2 - Mic Line
Selected RF Deck - MI2 Line
Selected RF Deck -
The External PTT (Voice) port goes low
level.
Control Head 1 - Mic Line
Selected RF Deck - MI2 Line
Unselected RF Deck -
The External PTT (Voice) port goes low
level.
Unselected RF Deck - MI2 Line
