Storing the GPS Data (GPS Data Storage)
GPS data can be stored in both internal memory and a microSD card.
In a Multi RF Deck/ Multi Control Head structure, the GPS data acquired by RF Deck 1 at the time interval configured in
GPS Storage Interval is transferred to RF Deck 2 and RF Deck 3.
The storing behavior of GPS data varies according to the configuration in SD Card Selection (RF Deck, Control Head 1,
Control Head 2).
0
RF Deck
The
GPS data is temporarily stored in the RAM of each RF Deck at the time interval configured in GPS Storage Interval.
If 3 pieces of GPS data are stored, these pieces of data are stored in both the internal memory of each RF Deck and a
micro SD card of each RF Deck. The GPS data (1 or 2 pieces) temporarily stored in the RAM of each RF Deck are deleted
without being stored in the internal memory and microSD card when the RF Deck is turned OFF. Whether to store the
GPS data can be configured for each microSD card inserted in each RF Deck.
GPS Data Transfer from RF Deck 1 to Each RF Deck Storage of GPS Data to the Internal Memory and microSD Card
GPS data transferred
GPS data transferred
Acquisition of 3 pieces
GPS data completed.
Figure 16-78 GPS Data Storage (RF Deck)
16 MULTI RF DECK/ MULTI CONTROL HEAD
16.17 microSD
Common FUNC (K, F)/Ver 2.20 320
