Control Head 1/ Control Head 2
The GPS data is temporarily stored in the RAM of each RF Deck at the time interval configured in GPS Storage
Interval.
If 3 pieces of GPS data are stored, these pieces of data are stored in both the internal memory of each RF Deck
and a micro SD card of Control Head 1/ Control Head 2 (KCH-20R). The GPS data (1 or 2 pieces) temporarily stored in
the RAM of each RF Deck are deleted without being stored in the internal memory and microSD card when the RF Deck
is turned OFF. Whether to store the GPS data in a microSD card inserted in Control Head 1/ Control Head 2 (KCH-20R)
can be configured.
GPS Data Transfer from RF Deck 1 to Each RF Deck Storage of GPS Data to the Internal Memory and microSD Card
GPS data transferred
GPS data transferred
Acquisition of 3 pieces
GPS data completed.
Figure 16-79 GPS Data Storage (Control Head 1/ Control Head 2)
Note
0
If the configuration data with Audio/GPS Data Erase (Internal Memory) enabled is written, the GPS data stored in the
internal memory of all RF Decks is deleted while “SELF TESTING” appears on the display.
0
If
a microSD card is ejected while GPS data is being saved into the microSD card, the GPS data file which is being saved
may not be saved correctly.
16 MULTI RF DECK/ MULTI CONTROL HEAD
16.17 microSD
Common FUNC (K, F)/Ver 2.20 321
