Kenwood NX-5200K3 Common Function Reference

2
Configure various functions of each RF Deck and Control Head in Transceiver Settings.
3
Select the configuration data of each RF Deck in Program > Multi RF Deck Setup.
Clicking the “Select File” button of RF Deck Data A to RF Deck Data C
selects the configuration data file of each
RF Deck.
Figure 17-75 Multi RF Deck Setup (RF Deck Data)
4
Configure Master Operation Data and click the “Write” button.
From RF Deck Data A to RF Deck Data C configured in step 3, the configuration data of which RF Deck is to be
the Master Operation Data is configured.
Figure 17-76 Multi RF Deck Setup (Master Operation Data)
Clicking the “Write” button displays RF Deck Selection.
17 STRUCTURING A MULTI RF DECK/ MULTI CONTROL HEAD
17.11 About Configuration Using KPG-D1/ D1N
Common FUNC (K, F)/Ver 2.20 379
CONTENTS INDEX
