Kenwood NX-5200K3 Common Function Reference

5
Configure FPU Data Select and click the “OK” button.
From RF Deck Data A to RF Deck Data C configured in step 3, the configuration data of which RF Deck is to be
written is configured for each RF Deck.
Figure 17-77 RF Deck Selection
Clicking the “OK” button displays Write Data to the Transceiver.
6
Click the “Write” button.
Figure 17-78 Write Data to the Transceiver
The writing of configuration data starts.
When the writing of configuration data completes, a writing complete message box appears. Click the “OK” button.
17 STRUCTURING A MULTI RF DECK/ MULTI CONTROL HEAD
17.11 About Configuration Using KPG-D1/ D1N
Common FUNC (K, F)/Ver 2.20 380
CONTENTS INDEX
