Function Name Description
Available
Communication
Systems
*1
Surveillance
Toggles the Surveillance between enabled and disabled. While the
Surveillance function is enabled, the transceiver does not emit a tone or light
the backlight even when the transceiver functions.
Note
For Mobile, this function cannot be used in a Multi RF Deck/ Dual Control
Head structure.
ALL
System Down
Decreases the system name in steps of 1. System Lock is enabled in the
selected system.
NXDN Trunking
System Down
(Continuous)
Pressing and holding the System Down
key causes the system name to be
decreased in steps of 1 every 100 ms. System Lock is enabled in the selected
system.
NXDN Trunking
System Lock Toggles the System Lock between enabled and disabled. NXDN Trunking
System Search
P25 Trunking:
The RFSS ID and Site ID of the site currently being used appears for 2 sec.
NXDN Trunking:
The Site No. appears.
See
0
P25 FUNC Manually Searching for a New Site (System Search)
0
NXDN
FUNC Starting the Control Channel Hunt Manually (Forced Search)
P25 Trunking
NXDN Trunking
System Search
Function
P25 Trunking:
Pressing and holding the System Search
key starts a system search.
NXDN Trunking:
Pressing and holding the System Search key starts a control channel hunt.
Note
System Search Function can be configured only in Hold for the System
Search key, and the configuration cannot be changed.
See
0
P25 FUNC Manually Searching for a New Site (System Search)
0
NXDN
FUNC Starting the Control Channel Hunt Manually (Forced Search)
P25 Trunking
NXDN Trunking
System Select Enters System Select Mode. NXDN Trunking
System Up
Increases the system name in steps of 1. System Lock is enabled in the
selected system.
NXDN Trunking
System Up
(Continuous)
Pressing and holding the System Up key causes the system name to be
increased
in steps of 1 every 100 ms. System Lock is enabled in the selected
system.
NXDN Trunking
Tactical Zone
When the transceiver is not in Tactical Zone Mode, pressing the Tactical
Zone
key registers the selected channel in Tactical Zone.
Analog Conventional
P25 Conventional
Tactical Zone (All
Channels)
When the transceiver is not in Tactical Zone Mode, pressing the Tactical
Zone
(All Channels) key registers all at once all the corresponding channels of the
selected zone in Tactical Zone.
Analog Conventional
P25 Conventional
Talk Around
Toggles the Talk Around between enabled and disabled.
See
0
P25 FUNC Communicating Without Using a Repeater (Talk Around)
0
NXDN FUNC Communicating Without Using a Repeater (Talk Around)
0
DMR
FUNC Communicating Without Using a Repeater (Talk Around/ DMR
Direct Mode)
Analog Conventional
P25 Conventional
NXDN Conventional
LTR Trunking
DMR Conventional
19 CONFIGURATION FOR EACH FUNCTION
19.1 Available Functions for the PF Keys
Common FUNC (K, F)/Ver 2.20 407
