Note
0
If the firmware is not written to the transceiver correctly, the transceiver will enter Firmware Programming Mode. In this
case, write the firmware to the transceiver again.
0
“UNPROGRAM”
appears on the main display if no data is written to the transceiver. In this case, data needs to be written
to the transceiver by using KPG-D1/ D1N.
0
In a Multi RF Deck system, pressing the Power switch for 1000 ms causes the transceiver to be turned ON.
0
The Power-on Tone A tone when the transceiver is turned ON can be created as desired using KPG-D1/ D1N.
Turning the Transceiver OFF
For Portable, rotate the Power switch counterclockwise until it clicks to turn the transceiver OFF.
For Mobile, pressing the Power
switch while the transceiver is turned ON causes the transceiver to be turned OFF. Also,
the transceiver can be turned OFF according to the status of the vehicle engine, either switched On or Off. (Refer to Turning
the Transceiver ON or OFF According to the State of the Ignition Sense Port (Ignition Sense).)
Also, for Mobile, pressing the Power switch for more than 5 sec forcibly turns the transceiver OFF. If the Power switch is
pressed while the transceiver is turned ON, or if an error occurs from when the Ignition Sense port goes low level until the
transceiver is turned OFF, or if a function in a P25 Trunking system, such as De-Registration, is functioning waiting for the
transmission or response of Suspended Power-off and Power-off Status, the transceiver may actually be in the ON state
even if nothing appears on the display. To turn the transceiver OFF immediately in this state, pressing the Power switch for
more than 5 sec forcibly turns the transceiver OFF. If “Ignition Only” is configured in Ignition Sense Type, the Ignition Sense
port needs to be at high level in order to turn the transceiver ON next time. In this case, the transceiver cannot be turned
ON by pressing the Power switch.
Power Switch Status Memory
Supported Models: Mobile
Power
Switch Status Memory is the function to configure whether to store the Power switch status (ON or OFF) when the
power source is disconnected from the transceiver.
Whether to turn the transceiver ON when the power source is connected to the transceiver depends as below on the
configuration in Power Switch Status Memory:
Table 3-1 Power Switch Status Memory
Configuration Description
Enabled
Enables the capability to retain the ON- or OFF-state of the Power
switch. By disconnecting the power
source while the transceiver Power switch is in the ON state and then by reconnecting the power source,
the transceiver is turned ON and starts up. Even if the power source is reconnected after the power
source is disconnected while the transceiver Power switch is in the OFF state, the transceiver remains
turned OFF. In this case, the transceiver does not start up unless the Power switch is pressed.
Disabled
Disables the capability to retain the ON- or OFF-state of the Power switch. Regardless of the previous
ON- or OFF-state of the Power switch, the transceiver power is turned ON by connecting the power
source to the transceiver.
Configuration using KPG-D1/ D1N
Configuring Power Switch Status Memory ( Transceiver Settings > Optional Features > Optional Features 1 >
Others)
3 BASIC OPERATIONS
3.1 Turning the Transceiver ON/ OFF
Common FUNC (K, F)/Ver 2.20 28
