Kenwood NX-5200K3 Common Function Reference

3.2
Adjusting the Volume Level
Portable
Rotating the Volume control clockwise increases the volume level from the speaker, and rotating the Volume control
counterclockwise decreases the volume level from the speaker.
Mobile
Pressing the Volume Up key increases the volume level in steps of 1. Pressing the Volume Down key decreases the
volume level in steps of 1. KCH-20R (Featured Panel) is operated by using the Volume control just as Portable.
If “Volume Up (Continuous)” or “Volume Down (Continuous)” is assigned to the Volume Up or Volume Down key, the
volume level is increased or decreased continuously every 100 ms by pressing and holding the Volume Up or Volume
Down key.
3.3
Using Function Keys
The following functions can be assigned to each key of the transceiver using KPG-D1/ D1N. Pressing a key to which a
function is assigned can activate the assigned function or place the transceiver in various Function Modes. (Refer to
Available Functions for the PF Keys.)
Following are the configuration examples for each key of the transceiver.
Table 3-2 Configuration Examples for Keys
Key Function 2nd Function Hold Hold Delay
Home ([T])
Home Channel None Home Channel Select 3.0
Back ([O])
Key Lock Autodial None 1.0
AUX Function None None 1.0
A function can be assigned to Function, 2nd Function and Hold of each key on the transceiver.
0
Function
The function is activated by pressing a key.
In the configuration example above, pressing the Home
([T]), Back ([O]), or AUX key activates the function assigned
to each key.
If a key to which Function is assigned is pressed, the transceiver waits for a function assigned to 2nd Function to be
activated.
0
2nd Function
The function is activated by pressing a key to which the function is assigned to 2nd Function after the Function key is
pressed.
In the configuration example above, pressing the Back ([O]) key after the AUX key is pressed activates the Autodial
function.
0
Hold
The function is activated by pressing and holding a key for the length of time configured for Hold Delay.
In the configuration example above, pressing and holding the Home ([T]) key for 3 sec activates the Home Channel
Select function.
Note
The two functions, Primary and Secondary, can be assigned to each key on the transceiver. Which function is used can
be configured for each zone or channel.
Configuration using KPG-D1/ D1N
Assigning functions to the PF
keys on the transceiver (
Transceiver Settings > Key Assignment)
3 BASIC OPERATIONS
3.2 Adjusting the Volume Level
Common FUNC (K, F)/Ver 2.20 29
CONTENTS INDEX
