8163A/B, 8164A/B, 8166A/B User’s Guide 137
Tunable Lasers 5
Figure 78 Setting Low SSE parameter
The LED beside the primary optical output is lit constantly, while the LED
beside the secondary optical output flashes. For example, if you select
<Both (master:2)> as the regulated path, the LED beside Output 2, the
High Power Output, is lit constantly and the LED beside Output 1, the Low
SSE optical output, flashes.
How to Set the Optical Output
1Move to [Output] and press Enter.
2 Move to your chosen optical output and press Enter.
How to Enable the Optical Output
3Move to [State] and press Enter.
If you select <Both (master:2)> or <Both (master:1)> as the regulated
path, both channels output optical power. You can only view or set the
parameters for the primary optical output, for example, the high power
output for <Both (master:2)>.
