316 8163A/B, 8164A/B, 8166A/B User’s Guide
11 Installation and Maintenance
AC Line Power Supply Requirements
Line Power Requirements
The 8163A/B Lightwave Multimeter System complies with overvoltage
category II and can operate from the single-phase AC power source that
supplies between 100 V and 240 V at a frequency in the range 50 to 60
Hz.The maximum power consumption is 120 VA with all options installed.
The 8164A/B Lightwave Measurement System complies with overvoltage
category II and can operate from any single-phase AC power source that
supplies between 100 V and 240 V at a frequency in the range from 50 to
60 Hz. The maximum power consumption is 270 VA with all options
installed.
The 8166A/B Lightwave Multichannel System complies with overvoltage
category II and can operate from any single-phase AC power source that
supplies between 100 V and 240 V at a frequency in the range from 50 to
60 Hz. The maximum power consumption is 450 VA with all options
installed.
Line Power Cable
In accordance with international safety standards, the instrument has a
three-wire power cable. When connected to an appropriate AC power
receptacle, this cable earths the instrument cabinet. For the part number
of the power cable for your country and instrument see Accessories on
page 345.
.
Figure 192 8163A/B Lightwave Multimeter System Power Key
