8163A/B, 8164A/B, 8166A/B User’s Guide 31

Getting Started 1

Laser Safety Labels

Laser class 1 label

Figure 1 Class 1 Safety Label - Keysight 81650A/51A/52A/54A/11A/12A/13A/14A

Laser class 1M label

Figure 2 Class 1M Safety Label - Keysight 81655A/6A/7A, 81662A/3A, 81600B

family, (81480B/82B/ 81640B/42B/80B/82B/72B),

81980A/40A/89A/49A, (81649A/89A/89B), 81606A/7A/8A/9A.
