8163A/B, 8164A/B, 8166A/B User’s Guide 359
Specifications and Regulations Compliance 13
Keysight 8164B Specifications
The Keysight 8164B Lightwave Measurement System displays five
channels.
[1]
Keysight 8163B Series modules are NOT compatible with the 8153A
Lightwave Multimeter.
[2]
For code compatibility to the 8153A Lightwave Multimeter please refer
to the mainframe’s Programming Guide, part number 08164-90B61.
Display Graphic color display 640 × 480 pixels visible.
VGA connector for external monitor.
Compatibility The Keysight 8164B mainframes support all HP 8153A Series and 8163A/B Series
modules.
[1]
Environmental
Storage temperature
Operating temperature
Humidity
-40° C to 70° C
10° C to 35° C
< 80% R.H. from 10° C to 35° C
Power AC 100 - 240 V ± 10%, 50 - 60 Hz, 280 VA max.
Dimensions 145 mm × 426 mm × 545 mm
(5.8" × 16.9" × 21.6")
Weight net, 20 kg (45 lb.), 23 kg (51 lb.), including modules.
GPIB interface
Function code
All modes and parameters accessible via GPIB interface.
SH1, AH1, T6, L4, SR0, RL1, PP0, DC1, DT0, C0.
SCPI standard;
[2]
GPIB Interface Performance max. 300 kB/s (burst data rate during read of 12001 points from a power meter).
Trigger True synchronous on all channels
Trigger Bandwidth max. 100 kHz for triggering, and
max. 1 MHz (50% duty cycle) for external digital modulation.
RS232C Interface: max. baud rate 115200 bps
Parallel Printer Interface Centronics
Number of Modules 4 front-loadable Modules, 1 back-loadable Module
External Keyboard PS/2 connector (reserved for future use)
Local Area Network (LAN) 10/100BASE-T Ethernet port
