8163A/B, 8164A/B, 8166A/B User’s Guide 415
Error Messages 14
Attenuator Modules
The following Error Codes are applicable to attenuator modules.
Codes E10010, E10012, and E10014 are valid for all attenuators. The
remaining codes are only valid for attenuators with power control
.
error message E10010: Invalid Caldata
description The Caldata loaded on the module is invalid. Either the caldata version number is not
compatible with the firmware or the caldata is corrupt (checksum incorrect)
test value (no test value)
action Please return the unit to your local service center for repair
error message E10012: Dual ported RAM write/read test failed
description Writing bit patterns and reading them back to/from the dual ported ram failed
test value (no test value)
action Please return the unit to your local service center for repair
error message E10013: FPGA not correctly initialized
description Loading the FPGA with data failed. This indicates a defective FPGA or an FPGA access
problem
test value (no test value)
action Please return the unit to your local service center for repair
error message E10014: Firmware corrupt, checksum error (a,b)
description Firmware in flash has an invalid checksum. Either the image which was programmed was
corrupt or the flash memory has a failure
test value a is the stored checksum
b is the calculated checksum
action Reload the module firmware. If the failure persists, please return the unit to your local
service center for repair
