Keysight Technologies 8163A - Specifications and Regulations Compliance; 8163 A Specifications

356 8163A/B, 8164A/B, 8166A/B User’s Guide
13 Specifications and Regulations Compliance
8163A Specifications
The 8163A Lightwave Multimeter displays two channels.
[1]
8163A Series modules are NOT compatible with the 8153A Lightwave
Multimeter.
[2]
For code compatibility to the 8153A Lightwave Multimeter please refer
to the mainframe’s Programming Guide, part number 08164-91016.
Display Graphical display 190 × 300 points visible, monochrome.
Display Resolution (Power Meters) 0.0001 dB/dBm, 0.01 pW to 10 pW (depending on power range), up to 6.5 digits (user
definable).
Compatibility The 8163A mainframe supports all 8153A Series.
[1]
Data Acquisitions
Memory>
Selectable data averaging time
Selectable total data averaging time
4000 measurement results / channel
depends on sensor module
20 ms to 23:59:59 h
Trigger True synchronous on all channels
Environmental
Storage temperature
Operating temperature
Humidity
-40° C to +70° C
0° C to +45° C
<95% R.H. from 0° C to +45° C
Power AC 100 - 240 V ± 10%, 48 - 66 Hz, 100 VA max.
Dimensions 88 mm × 213 mm × 380 mm
(3.5" × 8.4" × 15")
Weight net 4.200 kg (9.3 lbs); shipping 6.5 kg (14.5 lbs)
GPIB interface
Function code
All modes and parameters accessible via GPIB interface
SCPI standard
[2]
Interfaces Parallel port (Centronics)
Serial port (RS232)
Number of Modules 2 Modules
