Keysight Technologies 8163A - Laser Safety Information

8163A/B, 8164A/B, 8166A/B User’s Guide 23
Getting Started 1
Laser Safety Information
The laser sources specified by this user guide are classified according to
IEC 60825-1.
The laser sources comply with 21 CFR 1040.10 except for deviations
pursuant to Laser Notice No. 50 dated 2007-June-24.
Table 1 Initial Safety Information for Laser Source Modules
81650A 81651A 81652A 81654A
Laser type FP-Laser
InGaAsP
FP-Laser
InGaAsP
FP-Laser
InGaAsP
FP-Laser
InGaAsP
Wavelength (±15nm) 1310 nm 1550 nm 1550/1625 nm 1310/1550 nm
Max. CW output power
1
<1.8 mW <1.8 mW <1.8 mW <1.8 mW
Beam waist diameter 9 µm 9 µm 9 µm 9 µm
Numerical aperture 0.1 0.1 0.1 0.1
Laser Class according to
IEC 60825-1 (2007)
1111
Max. permissible CW output power 15.6 mW 10 mW 10 mW 15.6 mW/10 mW
1
Max. CW output power is defined as the highest possible optical power that the laser source can produce at its output connector.
