372 8163A/B, 8164A/B, 8166A/B User’s Guide
14 Error Messages
Screen Status Messages
Message Meaning Description
8163A/B 8164A/B
SL SLock Security Lock The module is locked for security reasons. No measurement is possible until you unlock
the module
RiL RiLock Remote InterLock The remote interlock connector of your mainframe is open. No measurement is possible
until the connection at the remote interlock connector closes
NoH No Head No Head There is an optical head interface module inserted in the mainframe that does not have
an Optical Head connected to it. No measurement is possible using this channel until
you:
- reconnect an optical head or
- deselect this optical channel as a power measurement channel
NoD No Data No Data No data has been measured or measurement is not finished. You cannot access the
analysis screen yet. Printout and file operations are not yet possible.
Set Settling Settling A tunable laser source module is settling. The instrument is busy and no measurement
can be performed yet.
NoR No Ref No Reference No reference sweep has been performed. Loss will be calculated using nominal laser
power as a reference.
B Busy Busy Module is busy performing last operation.
