30 8163A/B, 8164A/B, 8166A/B User’s Guide
1 Getting Started
Initial Safety Information for Return Loss Modules
Table 10 Return Loss Modules - Laser Safety Information
81611A 81612A 81613A 81614A
Laser type FP-Laser
InGaAsP
FP-Laser
InGaAsP
FP-Laser
InGaAsP
FP-Laser
InGaAsP
Wavelength (±15nm) 1310 nm 1550 nm 1550/1625 nm 1310/1550 nm
Max. CW output power
1
<1.8mW <1.8mW <1.8mW <1.8mW
Beam waist diameter 9 µm 9 µm 9 µm 9 µm
Numerical aperture 0.1 0.1 0.1 0.1
Laser Class according to IEC 60825-1 (2007) 1 1 1 1
Max. permissible CW output power 15.6 mW 10 mW 10 mW 15.6 mW/10 mW
1
Max. CW output power is defined as the highest possible optical power that the laser source can prodcue at its output connector
