8163A/B, 8164A/B, 8166A/B User’s Guide 25
Getting Started 1
Initial Safety Information for Tunable Laser Modules
Table 4 Backloadable Tunable Laser Modules - Laser Safety Information
81606A #216
81608A #216
81609A #216
81606A #116
81607A #116
81608A #116
81609A #116
81602A #013 81606A #113
81608A #113
81609A #113
Laser Type EC-Laser InGaAsP EC-Laser InGaAsP EC-Laser InGaAsP EC-Laser InGaAsP
Wavelength range 1450 – 1650 nm 1490 – 1640 nm 1250 - 1370 nm 1240 - 1380 nm
Max. CW output power
1
< 25 mW < 25 mW < 80 mW < 30 mW
Beam waist diameter 9 µm 9 µm 9 µm 9 µm
Numerical aperture 0.1 0.1 0.1 0.1
Laser Class according to
IEC 60825-1 (2014)
1M 1M 3B 1M
Max. permissible CW output power 163 mW 163 mW 500 mW 55 - 500 mW
1
Max. CW output power is defined as the highest possible optical power that the laser source can produce at its output connector.
