8163A/B, 8164A/B, 8166A/B User’s Guide 311

Applications 10

7 If you wish to change the suggested file name, use the on-screen

keyboard to modify the name.

8 Press [OK] to save the data to diskette using the displayed file name.

NOTE

Keysight 8164B Lightwave Measurement System mainframes do not

include a diskette ("floppy disk") drive.
