8163A/B, 8164A/B, 8166A/B User’s Guide 331
Installation and Maintenance 11
Figure 207 Removing a Back-Loadable Module from the 8164A/B
How to Fit a Back-Loadable Module
If you pull the module out at an angle or vertically, you may damage the
instrument and the module. You should pull the module out along the
direction shown in
Figure 207 on page -331
Disconnect all electrical and optical connectors before you fit this
module into the instrument, as this can cause damage to the connectors.
Make sure that the instrument is in stand-by mode, before you remove a
module.
