Saving a Waveform’s Settings & Parameters

2. If the desired catalog is not displayed, select it.

3. Highlight the desired waveform file and press Select Header.

The signal generator displays the file header for the selected waveform file.

4. To edit the header, press More, and proceed as described in Step4on page166 (Viewing and

Modifying File Header Information section).

Active waveform catalog

Active media

Type:

WFM1 = Volatile Segment

NVWFM = Non–Volatile Segment

SEQ = Sequence

Active catalog

For details on each key, use key help

as described on page56.

Catalogs that enable you to

view files in the active media.

For details on selecting the

active media, see page74.

Files in BBG media

Default Chapter5
