382 Keysight EXG and MXG X-Series Signal Generators User’s Guide

Using Avionics VOR/ILS Softkeys for N5171B/72B and N5181B/82B with Option 302

Using ILS Glide Slope Softkeys

To set the ILS Glide Slope up frequency

1. Press Aux Fctn > Avionics > ILS Glide Slope

2. Press Up/Down

3. Press Up Frequency

(Default <value> is 90 Hz.)

4. Select a <value> in Hz | kHz | MHz | GHz from 0 Hz to 6 MHz.

These softkeys set the ILS Glide Slope up frequency.

To set the ILS Glide Slope down frequency

1. Press Aux Fctn > Avionics > ILS Glide Slope

2. Press Up/Down

3. Press Down Frequency

(Default <value> is 150 Hz.)

4. Select a <value> in Hz | kHz | MHz | GHz from 0 Hz to 10 MHz.

These softkeys set the ILS Glide Slope down frequency.

16=109.55 16=332.45 36=111.55 36=332.75

17=109.70 17=333.20 37=111.70 37=333.50

18=109.75 18=333.05 38=111.75 38=333.35

19=109.90 19=333.80 39=111.90 39=331.10

20=109.95 20=333.65 40=111.95 40=330.95
